| Available in | Reverse Cycle - 11.2kW, 12.5kW, 18.0kW, 22.4kW, 25.0kW, 28.0kW |
| Refrigerant | R410A |
Key features
-
All DCWith All DC, electricity loss is decreased and power consumption is reduced.
-
Easy Maintenance & Service
Structural adjustments has improved serviceability of the unit.
-
High Static Pressure
Static pressure can be selected up 300Pa Max (72/90/96 models only).
-
Quiet Ducted Operation
Cutting off the corners of the conventional indoor unit front panel and fan casing has enabled less turbulent airflow.
-
Large Capacity Range
Capacities ranging from 11.2 to 28kW.
-
In-Built Safety TrayThe safety tray and drain port is in-built into the system.
Show entire range
Collapse range
Technical Specifications
| Attribute | ARXC36GATH 11.20kW(C) 12.50kW(H) View model | ARXC036GTEH 11.20kW(C) 12.50kW(H) View model | ARXC45GATH 12.50kW(C) 14.00kW(H) View model | ARXC60GATH 18.00kW(C) 20.00kW(H) View model | ARXC072GTEH 22.40kW(C) 25.00kW(H) View model | ARXC090GTEH 25.00kW(C) 28.00kW(H) View model | ARXC096GTEH 28.00kW(C) 31.50kW(H) View model |
|---|---|---|---|---|---|---|---|
|
Operation Type
|
Reverse Cycle | Reverse Cycle | Reverse Cycle | Reverse Cycle | Reverse Cycle | Reverse Cycle | Reverse Cycle |
|
Power Source
V/Ph/Hz
|
230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 | 230 / 1 / 50 |
|
Capacity Class
kW
|
11.2 | 11.2 | 12.5 | 18 | 22.4 | 25 | 28 |
|
Running Current
amps (Cooling / Heating)
|
1.76 / 1.76 | 1.25 / 1.25 | 3.14 / 3.14 | 3.15 / 3.15 | 4.1 / 4.1 | 4.86 / 4.86 | 4.89 / 4.89 |
|
Indoor Sound Pressure Cooling
dBA (High / Quiet)
|
45 / 32 | 42 / 32 | 49 / 42 | 49 / 42 | 47 / 40 | 48 / 44 | 48 / 42 |
|
Indoor Sound Pressure Heating
dBA (High / Quiet)
|
45 / 32 | 42 / 32 | 49 / 42 | 49 / 42 | 47 / 40 | 48 / 44 | 48 / 42 |
|
Static Pressure Range
PA (Min to Max)
|
100 to 200 | 0 to 200 | 100 to 250 | 100 to 250 | 0 to 300 | 0 to 300 | 0 to 300 |
|
Air Circulation (Indoor - High Fan) Cooling
l/sec
|
722 | 553 | 972 | 972 | 1083 | 1195 | 1347 |
|
Air Circulation (Indoor - High Fan) Heating
l/sec
|
722 | 553 | 972 | 972 | 1083 | 1195 | 1347 |
|
Indoor Unit Dimensions
mm (Height x Width x Depth)
|
400 x 1050 x 500 | 400 x 1050 x 500 | 400 x 1050 x 500 | 600 x 1050 x 500 | 450 x 1587 x 700 | 450 x 1587 x 700 | 550 x 1587 x 700 |
|
Indoor Unit Weight
kg
|
43.00 | 40.00 | 46.00 | 46.00 | 84.00 | 84.00 | 105.00 |
|
Piping Connects
mm Ø (Liquid / Gas)
|
9.52 / 19.05 | 9.52 / 15.88 | 9.52 / 19.05 | 9.52 / 19.05 | 9.52 / 19.05 | 9.52 / 19.05 | 9.52 / 22.22 |
|
Refrigerant Type
|
R410A | R410A | R410A | R410A | R410A | R410A | R410A |
